RC-Eurofighter 3d Printed
0
No Reviews
Brand: Aircombat3D
£24.00

Inclusive All Taxes

Seller
3DDesin
0
Ask a question

  • 1 Days Warranty

  • Shippment And Pickup

Description

Eurofighter 3d Printed Zoom 400% by R.Bächler richard.baechler@bluemail.ch

https://youtube.com/shorts/_WIL1yPFN1Q?feature=share
https://youtube.com/shorts/HmokK8pv1cY?feature=share
filamet
TPU :20g
PLA-LW Colorfab:1300g
https://colorfabb.com/how-to-print-with-lw-pla?msclkid=fb36bfb8c2d011ecb4881c618f6c73a3
PLA :200g

Eurofighter settings:
Weight2.9kg
Wingspan 1m
Leght1.3m
EDF 80mm 9blade6s 3.5k trust
Engine~3658-1920kV
5 Servos 15g MG 3.5kg
ECS80A
Accu 6S>40C5000-5500mAh
Retracts 3x 40g
Weels 3x150x55mm Tension front 3kg back 1.5-2kg
Alumium gear2+1 Retractable 130mm /55mm Spring modified for 2-3kg
CG:~20cm
QR14-20mm
SR13-19mm
Canard+3to +5degrees adjsutable by servo

Carbon tubes10mm :0.5+0.7m
8mm :3x0.5m
6mm: 0.5m

Steel wire 1.5mm 1m
glueCA glue medium 20g

Flightsettings:
Aileron QR 14-20mm
Rudder SR 13-19mm
Canard: +3to +4degrees on a servo for trimming

CG :around 20cm from base of mainwing
